• #15060-001 (102-2) 12 Volt w/6' (1.83m) leads with Deutsch connectors (replacement length) Stroke: 4-1/4" Length overall: 12-7/8" Length pin to pin: 12-1/4" Diameter (upper housing): 2-1/2"
• Top cap gland seal sheaths the actuator cable outer jacket as well as both internal conductors for maximum waterproofing Corrosion proof Vandar mounts Stainless steel ram won't flex, even under extreme loads Double O-ring for maximum protection Ballscrew rotates freely on 12 ball bearin
• Self-locking ballscrew locks into position and will not drift Precision molded, powdered metal, high alloy gears provide high accuracy, high wear resistance, and high strength for long life Tough, high-torque motor easily transfers 750 lbs. Kit includes 12-volt motor
• High-impact, ultraviolet resistant nylon 66, 50% glass fiber reinforced thermoplastic housing Corrosion proof Vandar cap and mount, stands up to severe loads Solid stainless steel billet end available for heavy duty, extreme duty and super strong applications
